Fluting&Testliner Paper Production Line Cylinder Mould Type

short description:

Cylinder Mould Type Fluting&Testliner Paper Production Line uses old cartons(OCC) and other mixed waste papers as raw material to produce 80-300 g/m² Testliner paper&Fluting paper. It adopts traditional Cylinder Mould to starch and form paper, mature technology, stable operation, simple structure and convenient operation. The Testliner&Fluting Paper Production Line has small investment, good return-profit, and carton packing paper product have huge demand in raising online shopping packaging market. It is one of our company’s best-selling machine.

Send email to us

Product Detail

Product Tags

Main Technical Parameter

1.Raw material	Old Carton,OCC
2.Output paper	Testliner paper,Kraftliner paper,Fluting paper,Kraft paper,Corrugated paper
3.Output paper weight	80-300 g/m²
4.Output paper width	1800-5100mm
5.Wire width	2300-5600 mm
6.Capacity	20-200 Tons Per Day
7. Working speed	50-180m/min
8. Design speed	80-210m/min
9.Rail gauge	2800-6200 mm
10.Drive way	Alternating current frequency conversion adjustable speed, sectional drive
11.Layout	Left or right hand machine

Process Technical Condition

Old cartons →Stock preparation system→Cylinder mould part→Press part→Dryer group→Sizing press part→Re-dryer group→Calendering part →Reeling part→Slitting&Rewinding part

Process Technical Condition

Requirements for Water, electricity, steam, compressed air and lubrication:

1.Fresh water and recycled use water condition:
Fresh water condition:clean,no color,low sand
Fresh water pressure used for boiler and cleaning system:3Mpa、2Mpa、0.4Mpa(3 kinds) PH value:6~8
Reuse water condition:
COD≦600 BOD≦240 SS≦80 ℃20-38 PH6-8

2. Power supply parameter
Voltage:380/220V±10%
Controlling system voltage:220/24V
Frequency:50HZ±2

3.Working steam pressure for dryer ≦0.5Mpa

4. Compressed air
● Air source pressure：0.6～0.7Mpa
● Working pressure：≤0.5Mpa
● Requirements： filtering、degreasing、dewatering、dry
Air supply temperature:≤35℃

Installation, Test Run And Training

(1)The seller will provide technical support and send engineers for installation, test run the whole paper production line and training the buyer's workers
(2)As different paper production line with different capacity, it will take different time to install and test run the paper production line. As usual, for regular paper production line with 50-100t/d, it will take about 4-5months,but mainly depend on the local factory and workers’ cooperation situation.
(3)The buyer shall be responsible for the salary, visa, round trip tickets, train tickets, accommodation and quarantine charges for the engineers
